Foot plate & floor mat
1.01.1 · TAIKON KT18 Pro (D902) · 4 items
Tap a number on the drawing to find the part in the list.
| Pos. | Description / Part no. | Qty | |
|---|---|---|---|
| 1 | Floor matTK-81-0001 | 1 | |
| 2 | Foot plate 1TK-61-0001 | 1 | |
| 3 | Upper structure frame ReferenceTK-62-0182 | 1 | |
| 4 | Foot plate 2TK-61-0002 | 1 |
